Grundfos CR 3-19 A-A-A-E-HQQE Vertical Multistage Centrifugal Pump – 96516603 (3 x 220-240D/380-415YV)
by Grundfos
SKU 96516603
Original price
$1,916.75
-
Original price
$1,916.75
Original price
$1,916.75
$1,916.75
-
$1,916.75
Current price
$1,916.75
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CR 3-19 A-A-A-E-HQQE is a vertical, non-self-priming, multistage in-line centrifugal pump designed for pipe system or foundation installation. It features a cast iron head and base with stainless steel wetted parts (EN 1.4301) for durability and efficiency across industrial, commercial, and agricultural water applications.
Key Applications & Benefits
- Commercial heating and air conditioning
- Commercial and industrial water pressure boosting
- District heating and district cooling systems
- Industrial water supply, wastewater, and process water treatment
- Desalination and reverse osmosis water treatment
- Drinking water treatment and distribution (WRAS & ACS approved)
- Irrigation, rotor & spray irrigation, and pivot systems
- Solar boosting, solar water solutions, and agricultural solar applications
- Livestock watering and community water supply solutions
Key Specifications:
| SKU | 96516603 |
| Rated Flow | 3 m³/h |
| Rated Head | 92.5 m |
| Maximum Head | 125.8 m |
| Pump Orientation | Vertical |
| Number of Stages | 19 |
| Maximum Operating Pressure | 16 bar |
| Liquid Temperature Range | -20 to 120 °C |
| Rated Motor Power (P2) | 1.5 kW |
| Motor Efficiency Class | IE3 |
| Shaft Seal | HQQE (Single) |
Documentation & Downloads:
| Document | Download |
|---|---|
| Grundfos CR 3-19 A-A-A-E-HQQE Product Datasheet | 📄 Download PDF |
