Grundfos CR 3-19 A-A-A-E-HQQE Vertical Multistage Centrifugal Pump – 92901511 (1 x 220-230V)
by Grundfos
SKU 92901511
Original price
$2,235.06
-
Original price
$2,235.06
Original price
$2,235.06
$2,235.06
-
$2,235.06
Current price
$2,235.06
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CR 3-19 A-A-A-E-HQQE is a high-performance vertical multistage centrifugal inline pump engineered for demanding commercial, industrial, and water treatment applications. It features a durable cast iron pump head and base, with all other wetted components manufactured from stainless steel (EN 1.4301) for excellent corrosion resistance. The integrated cartridge shaft seal ensures high operational reliability, safe handling, and simplified servicing, while the 1-phase, fan-cooled IE2 motor delivers efficient and dependable performance for continuous-duty operation.
Applications & Use Cases:
- Commercial heating and air conditioning systems
- Commercial water pressure boosting
- District heating and district cooling
- Industrial water supply and wastewater treatment
- Process liquid transfer and machining applications
- Desalination and reverse osmosis water treatment
- Drinking water treatment and water distribution
- Irrigation, pivot, and rotor & spray irrigation systems
- Solar boosting and solar water supply solutions
- Agricultural and livestock watering applications
Key Specifications:
| Model | CR 3-19 A-A-A-E-HQQE |
| SKU | 92901511 |
| Rated Flow | 3 m³/h |
| Rated Head | 84.1 m |
| Maximum Head | 122 m |
| Number of Stages | 19 |
| Pump Orientation | Vertical (Inline) |
| Maximum Operating Pressure | 16 bar |
| Liquid Temperature Range | -20 to 120 °C |
| Motor Power (P2) | 1.5 kW |
| Rated Voltage | 1 × 220–230 V, 50 Hz |
| Efficiency Class | IE2 |
Documentation & Downloads:
| Document | Download |
|---|---|
| Grundfos CR 3-19 Product Datasheet | 📄 Download PDF |
