Grundfos CR 3-15 A-A-A-E-HQQE Vertical Multistage Centrifugal Pump – 92901499 (1 x 220-230V)
by Grundfos
SKU 92901499
Original price
$1,822.56
-
Original price
$1,822.56
Original price
$1,822.56
$1,822.56
-
$1,822.56
Current price
$1,822.56
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CR 3-15 A-A-A-E-HQQE is a high-efficiency vertical, multistage centrifugal inline pump engineered for commercial, industrial, agricultural, and solar-powered water applications. The pump head and base are constructed from durable cast iron, while all wetted components are manufactured from corrosion-resistant stainless steel (EN 1.4301). A cartridge shaft seal ensures maximum reliability, safe handling, and simplified maintenance. Power transmission is achieved via a rigid split coupling, and the unit is driven by a 1-phase, fan-cooled asynchronous IEC motor.
Key Features & Typical Applications:
- Vertical multistage centrifugal inline pump design
- Cast iron pump head and base with stainless steel wetted parts
- High-reliability cartridge shaft seal (HQQE)
- Rigid split coupling for efficient and stable power transmission
- 1-phase, fan-cooled asynchronous motor (IE2 efficiency)
- Approved for drinking water use (WRAS & ACS)
- Ideal for heating, cooling, pressure boosting, irrigation, water treatment, and solar water systems
Key Specifications:
| Model | CR 3-15 A-A-A-E-HQQE |
| SKU | 92901499 |
| Rated flow | 3 m³/h |
| Rated head | 66.6 m |
| Maximum head | 96.4 m |
| Number of stages | 15 |
| Pump orientation | Vertical |
| Pumped liquid | Water |
| Liquid temperature range | -20 .. 120 °C |
| Maximum operating pressure | 16 bar |
| Motor power (P2) | 1.1 kW |
| Supply voltage | 1 × 220–230 V, 50 Hz |
| Efficiency class | IE2 |
| Net weight | 35.5 kg |
Documentation & Downloads:
| Document | Download |
|---|---|
| Grundfos Product Datasheet | 📄 Download PDF |
