Grundfos CR 3-13 A-A-A-E-HQQE Vertical Multistage Centrifugal Pump – 92901498 (1 x 220-230V)
by Grundfos
SKU 92901498
Original price
$1,711.19
-
Original price
$1,711.19
Original price
$1,711.19
$1,711.19
-
$1,711.19
Current price
$1,711.19
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CR 3-13 A-A-A-E-HQQE is a vertical, multistage centrifugal inline pump designed for demanding commercial, industrial, agricultural, and solar-powered water applications. The pump head and base are manufactured from cast iron, while all other wetted parts are made of high-grade stainless steel (EN 1.4301) to ensure durability and corrosion resistance. A cartridge shaft seal provides high operational reliability, safe handling, and easy maintenance. Power transmission is via a rigid split coupling, and the pump is equipped with a 1-phase, fan-cooled asynchronous motor.
Key Features & Applications:
- Vertical multistage centrifugal inline pump design
- Cast iron pump head and base with stainless steel wetted parts
- Cartridge shaft seal (HQQE) for high reliability and easy servicing
- Rigid split coupling for efficient power transmission
- 1-phase, fan-cooled asynchronous motor (IEC, IE2)
- Approved for drinking water applications (WRAS, ACS)
- Ideal for commercial heating & cooling, pressure boosting, irrigation, water treatment, and solar water solutions
Key Specifications:
| Model | CR 3-13 A-A-A-E-HQQE |
| SKU | 92901498 |
| Rated flow | 3 m³/h |
| Rated head | 58.9 m |
| Maximum head | 84.1 m |
| Number of stages | 13 |
| Pump orientation | Vertical |
| Pumped liquid | Water |
| Liquid temperature range | -20 .. 120 °C |
| Maximum operating pressure | 16 bar |
| Motor power (P2) | 1.1 kW |
| Supply voltage | 1 x 220–230 V, 50 Hz |
| Efficiency class | IE2 |
| Net weight | 34.6 kg |
Documentation & Downloads:
| Document | Download |
|---|---|
| Grundfos Product Datasheet | 📄 Download PDF |
