Grundfos CR 3-10 A-FGJ-A-E-HQQE Vertical Multistage Centrifugal Pump – 96516657 (3 x 220-240D/380-415YV)
by Grundfos
SKU 96516657
Original price
$1,353.00
-
Original price
$1,353.00
Original price
$1,353.00
$1,353.00
-
$1,353.00
Current price
$1,353.00
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CR 3-10 A-FGJ-A-E-HQQE is a vertical, non-self-priming,
multistage inline centrifugal pump designed for installation in pipe systems
and on a foundation. The pump features a cast iron head and base, with all
wetted parts made from stainless steel (EN 1.4301 / AISI 304).
It includes a single HQQE shaft seal, cast iron split coupling for power
transmission, and DIN / ANSI / JIS flange connections. Powered by a 3-phase
IEC motor (80A) with IE3 efficiency, it is suitable for commercial,
industrial, agricultural, and solar water applications.
Key Features & Benefits
- Vertical multistage centrifugal inline pump
- Cast iron pump head and base with stainless steel impellers
- Single HQQE cartridge shaft seal for reliable performance
- DIN / ANSI / JIS flange connections
- Approved for drinking water (WRAS & ACS)
- Wide liquid temperature range: -20°C to 120°C
- 3-phase IEC motor (80A) with IE3 efficiency
- Suitable for commercial, industrial, agricultural, and solar applications
Key Specifications
| Product Code | CR 3-10 A-FGJ-A-E-HQQE |
| Product Number | 96516657 |
| Rated Flow | 3 m³/h |
| Rated Head | 46.4 m |
| Maximum Head | 65.6 m |
| Stages / Impellers | 10 / 10 |
| Motor Power (P2) | 0.75 kW |
| Voltage / Frequency | 3 × 220-240D / 380-415Y V, 50 Hz |
| Max Operating Pressure | 25 bar |
| Liquid Temperature Range | -20 to 120 °C |
| Connection Size | DN 25/32 (1 1/4") |
| Shaft Seal | HQQE (Single) |
| Net Weight | 28.4 kg |
| Gross Weight | 31.2 kg |
| Country of Origin | TW |
Documentation & Downloads
| Document | Download |
|---|---|
| Product Datasheet / Technical PDF | 📄 Download PDF |
