Grundfos CR 20-17 A-F-A-E-HQQE Vertical Multistage Pump – 96500518 (3 x 380-415D/660-690YD)
by Grundfos
SKU 96500518
Original price
$9,508.81
-
Original price
$9,508.81
Original price
$9,508.81
$9,508.81
-
$9,508.81
Current price
$9,508.81
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CR 20-17 is a vertical, non-self-priming, multistage in-line centrifugal pump designed for high-head water transfer in commercial, industrial, and agricultural applications. Featuring stainless steel impellers and intermediate chambers, a cast iron pump head and base, and DIN flange connections, it delivers reliable performance and durability. Powered by a 3-phase IE3 motor, this pump is suitable for pressurized pipe systems and foundation mounting.
Suitable Applications
- Commercial heating and air conditioning
- Water pressure boosting for commercial, community, and industrial systems
- District heating and district cooling
- Industrial water supply and process liquids transfer
- Industrial wastewater and process water treatment
- Desalination and reverse osmosis water treatment
- Surface water intake and drinking water treatment
- Water distribution networks
- Irrigation: pivot, rotor, and spray systems
- Groundwater transfer applications
- Solar water boosting and supply solutions
- Agricultural solar solutions, fertigation, and dosing
- Livestock watering with solar-powered systems
Key Specifications
| Product Number | 96500518 |
| Rated Flow | 21 m³/h |
| Rated Head | 202.9 m |
| Maximum Head | 252 m |
| Number of Stages | 17 |
| Pump Orientation | Vertical |
| Maximum Operating Pressure | 25 bar |
| Liquid Temperature Range | -20 to 120 °C |
| Connection Type | DIN Flange, DN 50 (PN 25) |
| Motor Type | 160LB, 3-phase AC |
| Rated Motor Power (P2) | 18.5 kW |
| Supply Voltage | 3 × 380–415D / 660–690Y V, 50 Hz |
| Motor Efficiency Class | IE3 |
| Shaft Seal | HQQE (Single) |
| Approvals | CE, EAC, UKCA, SEPRO, WRAS, ACS |
| Net Weight | 186 kg |
Documentation & Downloads
| Product Datasheet (PDF) | Download |
