Grundfos CR 20-10 A-F-A-E-HQQE Vertical Multistage Pump – 96500515 (3 x 380-415D/660-690YD)

The Grundfos CR 20-10 is a vertical, non-self-priming, multistage in-line centrifugal pump designed for high-head water transfer in commercial, industrial, and agricultural applications. It features stainless steel impellers and intermediate chambers with a cast iron pump head and base, providing durability and corrosion resistance. Equipped with DIN flange connections and a high-efficiency 3-phase IE3 motor, it ensures reliable operation in pressurised pipe systems.

Suitable Applications

• Commercial heating and air conditioning systems
• Water pressure boosting for commercial, community, and industrial use
• District heating and district cooling
• Industrial water supply and process liquids transfer
• Industrial wastewater and process water treatment
• Desalination and reverse osmosis systems
• Surface water intake and drinking water treatment
• Water distribution networks
• Irrigation, pivot, rotor, and spray irrigation
• Groundwater transfer applications
• Solar water boosting and supply solutions
• Solar-powered irrigation, fertigation, and dosing systems
• Agricultural and livestock watering solutions

Key Specifications

Documentation & Downloads
