Grundfos CR 15-12 A-F-A-E-HQQE Vertical Multistage Pump – 96501902 (3 x 380-415D/660-690YD)
by Grundfos
SKU 96501902
Original price
$5,898.06
-
Original price
$5,898.06
Original price
$5,898.06
$5,898.06
-
$5,898.06
Current price
$5,898.06
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CR 15-12 A-F-A-E-HQQE is a vertical, non-self-priming, multistage in-line centrifugal pump designed for installation in pipe systems or mounting on a foundation. It features a cast iron pump head and base, with all other wetted parts manufactured from stainless steel (EN 1.4301), ensuring high corrosion resistance, reliable performance, and suitability for high-pressure water supply and treatment duties.
Suitable Applications
- Commercial heating and air conditioning
- Commercial water pressure boosting
- District heating and district cooling
- Machining, wash-down, and cleaning systems
- Process liquids transfer
- Industrial heating and cooling systems
- Industrial water supply and wastewater systems
- Industrial process water treatment
- Desalination and reverse osmosis systems
- Surface water intake and drinking water treatment
- Water distribution and community water supply
- Irrigation and agricultural water systems
- Groundwater transfer and pivot irrigation
- Solar water boosting and solar water supply solutions
- Livestock watering with solar solutions
Key Specifications
| Model | CR 15-12 A-F-A-E-HQQE |
| Product Number | 96501902 |
| Pump Type | Vertical multistage centrifugal, in-line |
| Rated Flow | 17 m³/h |
| Rated Head | 135.6 m |
| Maximum Head | 169 m |
| Number of Stages | 12 |
| Pumped Liquid | Water |
| Liquid Temperature Range | -20 to 120 °C |
| Maximum Operating Pressure | 25 bar |
| Connection Type | DIN flanged |
| Inlet / Outlet Size | DN 50 / DN 50 |
| Pressure Rating | PN 25 |
| Impeller Material | Stainless steel (EN 1.4301 / AISI 304) |
| Pump Head & Base | Cast iron (EN-GJL-200) |
| Shaft Seal | Single, HQQE (EN 12756) |
| Motor Power (P2) | 11 kW |
| Motor Efficiency Class | IE3 |
| Rated Speed | 2940–2950 rpm |
| Voltage | 3 × 380–415D / 660–690Y V |
| Frequency | 50 Hz |
| Approvals | CE, EAC, UKCA, SEPRO |
| Drinking Water Approvals | WRAS, ACS |
| Net Weight | 153 kg |
Documentation & Downloads
| Product Data Sheet (PDF) | Download |
