Grundfos CR 1-5 A-A-A-E-HQQE Vertical Multistage Centrifugal Pump – 96516173 (3 x 220-240D/380-415YV)
by Grundfos
SKU 96516173
Original price
$992.06
-
Original price
$992.06
Original price
$992.06
$992.06
-
$992.06
Current price
$992.06
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CR 1-5 A-A-A-E-HQQE is a vertical, non-self-priming, multistage, in-line centrifugal pump designed for reliable operation in water supply, pressure boosting, heating, cooling, and industrial process applications. The pump head and base are manufactured from cast iron, while all wetted parts are stainless steel (EN 1.4301), providing excellent durability and corrosion resistance.
Suitable Applications
- Commercial heating and air conditioning
- Commercial water pressure boosting
- District heating and cooling
- Industrial heating and cooling
- Industrial water supply and wastewater
- Industrial process water treatment
- Desalination and reverse osmosis systems
- Surface water intake and drinking water treatment
- Water distribution systems
- Irrigation, rotor & spray irrigation
- Groundwater transfer and community water supply
- Solar water solutions and solar boosting
- Agriculture and livestock watering with solar solutions
Key Specifications
| Product Name | CR 1-5 A-A-A-E-HQQE |
| Product Number | 96516173 |
| Phase | 3 Phase |
| Phase / Volts | 3 × 220–240Δ / 380–415Y V |
| Volts | 220–240 V Δ / 380–415 V Y |
| Motor Type | 3-phase AC motor, IEC, IE3 efficiency |
| Motor Power (P2) | 0.37 kW |
| Rated Flow | 1.8 m³/h |
| Rated Head | 24.9 m |
| Maximum Head | 31.6 m |
| Stages / Impellers | 5 / 5 |
| Pump Orientation | Vertical |
| Shaft Seal | Single mechanical seal (HQQE) |
| Maximum Operating Pressure | 16 bar |
| Liquid Temperature Range | -20 °C to 120 °C |
| Flanges / Connections | Oval / Rp, PN 16 |
| Inlet / Outlet Size | 1 inch / 1 inch |
| Material | Cast iron pump head & base, stainless steel (EN 1.4301) impellers |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
| Net Weight | 19.4 kg |
| Country of Origin | Taiwan |
Documentation & Downloads
| CR 1-5 A-A-A-E-HQQE Datasheet | Download PDF |
