Grundfos CR 1-4 A-FGJ-A-E-HQQE Vertical Multistage Centrifugal Pump – 96516241 (3 x 220-240D/380-415YV)
by Grundfos
SKU 96516241
Original price
$1,019.56
-
Original price
$1,019.56
Original price
$1,019.56
$1,019.56
-
$1,019.56
Current price
$1,019.56
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CR 1-4 A-FGJ-A-E-HQQE is a vertical, non-self-priming, multistage in-line centrifugal pump for installation in pipe systems or mounting on a foundation. It features suction and discharge ports on the same level, a cast iron pump head and base, and stainless steel wetted parts (EN 1.4301). The pump is fitted with a single HQQE shaft seal, rigid cast iron split coupling, DIN/ANSI/JIS flanged connections, and a high-efficiency IE3 three-phase AC motor.
Suitable Applications
- Commercial heating and air conditioning
- Commercial water pressure boosting
- District heating and cooling
- Industrial heating and cooling
- Industrial water supply and wastewater
- Industrial process water treatment
- Machining, wash and clean applications
- Process liquids transfer
- Desalination and reverse osmosis systems
- Surface water intake and groundwater transfer
- Drinking water treatment and water distribution
- Irrigation, pivot and rotor & spray irrigation
- Solar water solutions and solar boosting systems
- Community water supply and livestock watering
- Fertigation, dosing, and digital water management
Key Specifications
| Product Model | CR 1-4 A-FGJ-A-E-HQQE |
| Product Number | 96516241 |
| EAN | 5700396739274 |
| Pump Type | Vertical multistage centrifugal, in-line |
| Pump Orientation | Vertical |
| Rated Flow | 1.8 m³/h |
| Rated Head | 20.3 m |
| Maximum Head | 25.4 m |
| Stages | 4 |
| Impellers | 4 |
| Pump Speed (Data Basis) | 2873 rpm |
| Curve Tolerance | ISO 9906:2012 3B |
| Pumped Liquid | Water |
| Liquid Temperature Range | -20 to 120 °C |
| Selected Liquid Temperature | 20 °C |
| Density | 998.2 kg/m³ |
| Pump Head & Base | Cast iron (EN-GJL-200 / ASTM A48-25B) |
| Impellers Material | Stainless steel EN 1.4301 (AISI 304) |
| Bearing | SIC |
| Shaft Seal Arrangement | Single |
| Primary Shaft Seal | HQQE |
| Rubber Components | EPDM (Code E) |
| Type of Connection | DIN / ANSI / JIS flanges |
| Inlet Connection Size | DN 25/32 (1 1/4 inch) |
| Outlet Connection Size | DN 25/32 (1 1/4 inch) |
| Pressure Rating | PN 25 |
| Maximum Operating Pressure | 25 bar |
| Maximum Ambient Temperature | 60 °C |
| Phase / Volts | 3-phase, 220–240D / 380–415Y V |
| Frequency | 50 Hz |
| Motor Type | IEC 71A |
| Motor Efficiency Class | IE3 |
| Motor Power (P2) | 0.37 kW |
| Rated Speed | 2850–2880 rpm |
| Rated Current | 1.74 / 1.00 A |
| Power Factor (Cos φ) | 0.80 – 0.70 |
| Enclosure Class | IP55 (Dust / Jetting) |
| Insulation Class | F |
| Approvals | CE, EAC, UKCA, SEPRO, RCM |
| Drinking Water Approvals | WRAS, ACS |
| Minimum Efficiency Index (MEI) | ≥ 0.70 |
| Net Weight | 23.5 kg |
| Gross Weight | 26.1 kg |
| Shipping Volume | 0.054 m³ |
| Country of Origin | TW |
Documentation & Downloads
| CR 1-4 A-FGJ-A-E-HQQE Datasheet | Download PDF |
