Grundfos CR 1-36 A-FGJ-A-E-HQQE Vertical Multistage Centrifugal Pump – 92901052 (1 x 220-230V)
by Grundfos
SKU 92901052
Original price
$3,183.13
-
Original price
$3,183.13
Original price
$3,183.13
$3,183.13
-
$3,183.13
Current price
$3,183.13
📢 For orders over $100, FREE Shipping Australia-wide
Vertical, multistage centrifugal inline pump with suction and discharge ports on the same level. The pump head and base are cast iron, and all other wetted parts are stainless steel (EN 1.4301). Equipped with a cartridge shaft seal for high reliability and easy maintenance, power is transmitted via a rigid split coupling. Pipe connections use combined DIN / ANSI / JIS flanges. Fitted with a 1-phase, fan-cooled asynchronous motor.
Suitable Applications
- Commercial heating and air conditioning
- Commercial water pressure boosting
- District heating and cooling
- Industrial water supply and wastewater
- Process water treatment and desalination
- Drinking water treatment and distribution
- Irrigation, community water supply, and solar water solutions
- Agricultural solar solutions, fertigation, and livestock watering
Key Specifications
| Product Model | CR 1-36 A-FGJ-A-E-HQQE |
| Product Number | 92901052 |
| Phase / Voltage | 1 Phase / 220–230 V |
| Frequency | 50 Hz |
| Motor Type | Fan-cooled asynchronous (IEC 90LD) |
| Motor Power (P2) | 2.2 kW |
| Rated Flow | 1.8 m³/h |
| Rated Head | 155.4 m |
| Maximum Head | 216.9 m |
| Stages / Impellers | 36 / 36 |
| Pump Orientation | Vertical (Inline) |
| Shaft Seal | Single mechanical seal (HQQE) |
| Maximum Operating Pressure | 25 bar |
| Liquid Temperature Range | -20 °C to 120 °C |
| Flanges | DIN / ANSI / JIS, DN 25/32 (1 1/4 inch), PN 25 |
| Material | Base & pump head: Cast iron; Wetted parts & impellers: Stainless steel (EN 1.4301 / AISI 304) |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
| Net Weight | 53.4 kg |
| Gross Weight | 58 kg |
| Country of Origin | AU |
| Price | AUD 4630 |
Documentation & Downloads
| CR 1-36 A-FGJ-A-E-HQQE Datasheet | Download PDF |
