Grundfos CR 1-33 A-FGJ-A-E-HQQE Vertical Multistage Centrifugal Pump – 96516258 (3 x 220-240D/380-415YV)
by Grundfos
SKU 96516258
Original price
$2,672.31
-
Original price
$2,672.31
Original price
$2,672.31
$2,672.31
-
$2,672.31
Current price
$2,672.31
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CR 1-33 A-FGJ-A-E-HQQE is a vertical, non-self-priming, multistage, in-line centrifugal pump designed for installation in pipe systems or mounting on a foundation. Suction and discharge ports are positioned on the same level. The pump head and base are manufactured from cast iron, while all wetted parts are made of stainless steel (EN 1.4301), providing high corrosion resistance and reliable performance in commercial, industrial, and water treatment applications.
Suitable Applications
- Commercial heating and air conditioning
- Commercial water pressure boosting
- District heating and district cooling
- Machining, wash and clean applications
- Process liquids transfer
- Industrial heating and cooling
- Industrial water supply and wastewater
- Industrial process water treatment
- Desalination and reverse osmosis water treatment
- Surface water intake
- Drinking water treatment and water distribution
- Irrigation and agriculture
- Solar water solutions and boosting
- Community and groundwater supply
- Rotor, pivot, and spray irrigation
- Livestock watering with solar solutions
- Controls and digital water management
Key Specifications
| Product Model | CR 1-33 A-FGJ-A-E-HQQE |
| Product Number | 96516258 |
| EAN | 5700396739618 |
| Phase | 3 Phase |
| Rated Voltage | 3 × 220–240D / 380–415Y V |
| Frequency | 50 Hz |
| Motor Standard | IEC |
| Motor Type | 90LE |
| Motor Power (P2) | 2.2 kW |
| IE Efficiency Class | IE3 |
| Pump Speed (Data Based) | 2899 rpm |
| Rated Speed | 2890–2910 rpm |
| Rated Flow | 1.8 m³/h |
| Rated Head | 158.9 m |
| Maximum Head | 206.2 m |
| Stages | 33 |
| Impellers | 33 |
| Pump Orientation | Vertical (Inline) |
| Shaft Seal Arrangement | Single |
| Primary Shaft Seal | HQQE |
| Pumped Liquid | Water |
| Liquid Temperature Range | -20 °C to 120 °C |
| Selected Liquid Temperature | 20 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DIN / ANSI / JIS flanges, DN 25/32 (1 1/4"), PN 25 |
| Materials |
Pump head & base: Cast iron (EN-GJL-200, ASTM A48-25B) Impellers & wetted parts: Stainless steel (EN 1.4301 / AISI 304) Bearing: SIC |
| Approvals | CE, EAC, UKCA, SEPRO, RCM |
| Drinking Water Approvals | WRAS, ACS |
| Curve Tolerance | ISO 9906:2012 3B |
| Minimum Efficiency Index (MEI) | ≥ 0.70 |
| Net Weight | 50.1 kg |
| Gross Weight | 54.8 kg |
| Country of Origin | TW |
Documentation & Downloads
| Product datasheet – CR 1-33 A-FGJ-A-E-HQQE | Download PDF |
