Grundfos CR 1-3 A-A-A-E-HQQE Vertical Multistage Centrifugal Pump – 92900963 (1 x 220-230V)
by Grundfos
SKU 92900970
Original price
$1,083.50
-
Original price
$1,083.50
Original price
$1,083.50
$1,083.50
-
$1,083.50
Current price
$1,083.50
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CR 1-3 A-A-A-E-HQQE is a vertical, multistage, in-line centrifugal pump with suction and discharge ports on the same level. The pump head and base are made of cast iron, while all other wetted parts are stainless steel (EN 1.4301) for excellent durability and corrosion resistance.
Equipped with a cartridge shaft seal (HQQE) for high reliability and safe handling, this pump features rigid split coupling power transmission and is fitted with a single-phase, fan-cooled asynchronous motor. It is suitable for commercial, industrial, agricultural, and water supply applications.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean
- Process liquids transfer
- Industrial heating
- Cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination
- Reversed Osmosis - Water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation
- Solar water solutions
- Community water supply
- Rotor & spray irrigation
- Ground water transfer
- Pivot
- Solar boosting and water supply solutions
- Controls & Digital Groundwater Management
- Solar Controls & Digital Water Management
- Solar Water Treatment Fertigation & Dosing
- Agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Name | CR 1-3 A-A-A-E-HQQE |
| Product Number | 92900963 |
| Rated Flow | 1.8 m³/h |
| Rated Head | 15.4 m |
| Maximum Head | 19.1 m |
| Stages / Impellers | 3 / 3 |
| Pump Orientation | Vertical |
| Shaft Seal Arrangement | Single |
| Primary Shaft Seal | HQQE |
| Maximum Operating Pressure | 16 bar |
| Liquid Temperature Range | -20 °C to 120 °C |
| Pumped Liquid | Water |
| Base Material | Cast iron (EN 1561 EN-GJL-200 / ASTM A48-25B) |
| Impeller Material | Stainless steel (EN 1.4301 / AISI 304) |
| Bearing | SIC |
| Connection Type | Oval / Rp |
| Inlet / Outlet Size | 1 inch / 1 inch |
| Pressure Rating | PN 16 |
| Flange Size for Motor | FT85 |
| Rated Voltage | 220-230 V |
| Phase | 1 |
| Motor Type | 71C, single-phase, fan-cooled asynchronous |
| Motor Power | 0.37 kW |
| Rated Current | 2.50–2.60 A |
| Rated Speed | 2700–2730 rpm |
| Motor Efficiency Class | IE2 |
| Approvals | CE, EAC, UKCA, SEPRO, RCM |
| Approvals for Drinking Water | WRAS, ACS |
| Net Weight | 21.3 kg |
| Gross Weight | 24 kg |
| Country of Origin | AU |
Documentation & Downloads
| CR 1-3 A-A-A-E-HQQE Datasheet | 📄 Download PDF |
