Grundfos CR 1-21 A-FGJ-A-E-HQQE Vertical Multistage Centrifugal Pump – 96516253 (3 x 220-240D/380-415YV)
by Grundfos
SKU 96516253
Original price
$1,799.19
-
Original price
$1,799.19
Original price
$1,799.19
$1,799.19
-
$1,799.19
Current price
$1,799.19
📢 For orders over $100, FREE Shipping Australia-wide
Vertical, multistage centrifugal pump with suction and discharge ports on the same level. The pump head and base are manufactured from cast iron, while all other wetted parts are stainless steel (EN 1.4301). This non-self-priming, in-line centrifugal pump is designed for installation in pipe systems and mounting on a foundation. Impellers and intermediate chambers are stainless steel, the shaft seal assembly complies with EN 12756, power transmission is via cast iron split coupling, and pipework connection is through DIN / ANSI / JIS flanges. The pump is fitted with a 3-phase AC motor.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating and cooling
- Industrial heating and cooling
- Industrial water supply and wastewater
- Industrial process water treatment
- Desalination and reverse osmosis
- Drinking water treatment and distribution
- Irrigation and agriculture
- Solar water and boosting solutions
- Groundwater transfer and community water supply
- Livestock watering with solar solutions
Key Specifications
| Product Model | CR 1-21 A-FGJ-A-E-HQQE |
| Product Number | 96516253 |
| EAN | 5700396739519 |
| Phase | 3 Phase |
| Voltage | 3 × 220–240D / 380–415Y V |
| Frequency | 50 Hz |
| Motor Type | IEC 80C, IE3 efficiency class |
| Motor Power (P2) | 1.1 kW |
| Rated Speed | 2840–2870 rpm |
| Pump Speed (Data Based) | 2853 rpm |
| Rated Flow | 1.8 m³/h |
| Rated Head | 96.6 m |
| Maximum Head | 129.2 m |
| Stages / Impellers | 21 / 21 |
| Pump Orientation | Vertical (Inline) |
| Shaft Seal | Single mechanical seal (HQQE) |
| Liquid Temperature Range | -20 °C to 120 °C |
| Maximum Operating Pressure | 25 bar |
| Flanges | DIN / ANSI / JIS, DN 25/32 (1 1/4 inch), PN 25 |
| Material |
Base & pump head: Cast iron (EN-GJL-200) Impellers & wetted parts: Stainless steel (EN 1.4301 / AISI 304) |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
| Minimum Efficiency Index (MEI) | ≥ 0.70 |
| Net Weight | 34.9 kg |
| Country of Origin | TW |
Documentation / Downloads
| Product datasheet – CR 1-21 A-FGJ-A-E-HQQE | Download PDF |
