Grundfos CR 1-2 A-FGJ-A-E-HQQE Vertical Multistage Centrifugal Pump – 96516239 (3 x 220-240D/380-415YV)
by Grundfos
SKU 96516239
Original price
$951.50
-
Original price
$951.50
Original price
$951.50
$951.50
-
$951.50
Current price
$951.50
📢 For orders over $100, FREE Shipping Australia-wide
Vertical, multistage centrifugal inline pump with suction and discharge ports on the same level. The pump head and base are manufactured from cast iron, while all other wetted parts are in stainless steel (EN 1.4301). The pump uses a cartridge shaft seal with assembly length according to EN 12756 for reliable operation and ease of service. Power transmission is via a cast iron split coupling, and pipe connections are through combined DIN / ANSI / JIS flanges. The pump is fitted with a 3-phase AC motor.
Suitable Applications
- Commercial heating and air conditioning
- Commercial water pressure boosting
- District heating and cooling
- Industrial water supply and wastewater
- Process liquids transfer and industrial process water treatment
- Desalination and reverse osmosis water treatment
- Drinking water treatment and distribution
- Irrigation, community water supply, and solar water solutions
- Agriculture, fertigation, and livestock watering with solar solutions
Key Specifications
| Product Model | CR 1-2 A-FGJ-A-E-HQQE |
| Product Number | 96516239 |
| Phase / Voltage | 3 Phase / 220–240 V (Delta) / 380–415 V (Star) |
| Frequency | 50 Hz |
| Motor Type | IEC 71A, 3-phase AC motor |
| Motor Power (P2) | 0.37 kW |
| Rated Flow | 1.8 m³/h |
| Rated Head | 9.8 m |
| Maximum Head | 12.1 m |
| Stages / Impellers | 3 / 2 |
| Pump Orientation | Vertical (Inline) |
| Shaft Seal | Single mechanical seal (HQQE) |
| Maximum Operating Pressure | 25 bar |
| Liquid Temperature Range | -20 °C to 120 °C |
| Flanges | DIN / ANSI / JIS, DN 25/32 (1 1/4 inch), PN 25 |
| Material | Base & pump head: Cast iron; Wetted parts & impellers: Stainless steel (EN 1.4301 / AISI 304) |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
| Net Weight | 22.9 kg |
| Gross Weight | 25.5 kg |
| Country of Origin | TW |
| Price | AUD 1384 |
Documentation & Downloads
| CR 1-2 A-FGJ-A-E-HQQE Datasheet | Download PDF |
