Grundfos CR 1-19 A-A-A-E-HQQE Vertical Multistage Centrifugal Pump – 96516190 (3 x 220-240D/380-415YV)
by Grundfos
SKU 96516190
Original price
$1,630.06
-
Original price
$1,630.06
Original price
$1,630.06
$1,630.06
-
$1,630.06
Current price
$1,630.06
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CR 1-19 A-A-A-E-HQQE is a vertical, non-self-priming, multistage, in-line centrifugal pump suitable for pipe system or foundation installation. Featuring a cast iron pump head and base and stainless steel (EN 1.4301) wetted parts, this pump is ideal for industrial, water treatment, irrigation, and solar water applications, offering high efficiency and long-lasting performance.
Suitable Applications
- Commercial heating and air conditioning
- Commercial water pressure boosting
- District heating and cooling
- Industrial heating and cooling
- Industrial water supply and wastewater
- Industrial process water treatment
- Desalination and reverse osmosis systems
- Surface water intake and drinking water treatment
- Water distribution networks
- Irrigation, rotor & spray irrigation, and pivot systems
- Groundwater transfer and community water supply
- Solar water solutions, solar boosting systems, and digital water management
- Agriculture and livestock watering with solar solutions
Key Specifications
| Product Name | CR 1-19 A-A-A-E-HQQE |
| Product Number | 96516190 |
| Phase | 3 Phase |
| Phase / Volts | 3 × 220–240Δ / 380–415Y V |
| Motor Type | 3-phase AC motor, IEC 80C, IE3 efficiency |
| Motor Power (P2) | 1.1 kW |
| Rated Flow | 1.8 m³/h |
| Rated Head | 88.4 m |
| Maximum Head | 117.4 m |
| Stages / Impellers | 19 / 19 |
| Pump Orientation | Vertical |
| Shaft Seal | Single mechanical seal (HQQE) |
| Maximum Operating Pressure | 16 bar |
| Liquid Temperature Range | -20 °C to 120 °C |
| Flanges / Connections | Oval / Rp, PN 16 |
| Inlet / Outlet Size | 1 inch / 1 inch |
| Material | Cast iron pump head & base, stainless steel (EN 1.4301) impellers |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
| Net Weight | 29.5 kg |
| Gross Weight | 33.6 kg |
| Country of Origin | Taiwan |
Documentation & Downloads
| CR 1-19 A-A-A-E-HQQE Datasheet | Download PDF |
