Grundfos CR 1-19 A-A-A-E-HQQE Vertical Multistage Centrifugal Pump – 92901383 (1 x 220-230V)
by Grundfos
SKU 92901383
Original price
$1,867.94
-
Original price
$1,867.94
Original price
$1,867.94
$1,867.94
-
$1,867.94
Current price
$1,867.94
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CR 1-19 A-A-A-E-HQQE is a vertical, multistage, inline centrifugal pump with suction and discharge ports on the same level. The pump head and base are manufactured from cast iron, while all other wetted parts are in stainless steel (EN 1.4301) to ensure high corrosion resistance and long service life.
A cartridge shaft seal (HQQE) provides reliable operation and easy servicing. Power transmission is via a rigid split coupling, and the pump is fitted with a single-phase, fan-cooled asynchronous motor, making it suitable for demanding commercial, industrial, agricultural, and water supply applications.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean
- Process liquids transfer
- Industrial heating
- Cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination
- Reverse osmosis water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation
- Solar water solutions
- Community water supply
- Rotor & spray irrigation
- Ground water transfer
- Pivot irrigation
- Solar boosting and water supply solutions
- Controls and digital groundwater management
- Solar controls and digital water management
- Solar water treatment fertigation and dosing
- Agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Name | CR 1-19 A-A-A-E-HQQE |
| Product Number | 92901383 |
| Rated Flow | 1.8 m³/h |
| Rated Head | 85 m |
| Maximum Head | 115.8 m |
| Stages / Impellers | 19 / 19 |
| Pump Orientation | Vertical |
| Shaft Seal Arrangement | Single |
| Primary Shaft Seal | HQQE |
| Maximum Operating Pressure | 16 bar |
| Liquid Temperature Range | -20 °C to 120 °C |
| Pumped Liquid | Water |
| Base Material | Cast iron (EN 1561 EN-GJL-200 / ASTM A48-25B) |
| Impeller Material | Stainless steel (EN 1.4301 / AISI 304) |
| Bearing | SIC |
| Connection Type | Oval / Rp |
| Inlet / Outlet Size | 1 inch / 1 inch |
| Pressure Rating | PN 16 |
| Flange Size for Motor | FT115 |
| Rated Voltage | 220–230 V |
| Phase | 1 |
| Motor Type | 90SE, single-phase, fan-cooled asynchronous |
| Motor Power | 1.1 kW |
| Rated Current | 6.30–6.60 A |
| Rated Speed | 2880–2890 rpm |
| Motor Efficiency Class | IE2 |
| Approvals | CE, EAC, UKCA, SEPRO, RCM |
| Approvals for Drinking Water | WRAS, ACS |
| Net Weight | 37.2 kg |
| Gross Weight | 41.3 kg |
| Country of Origin | AU |
| EAN Number | 5715121284257 |
| Price | AUD 2717 |
Documentation & Downloads
| CR 1-19 A-A-A-E-HQQE Datasheet | 📄 Download PDF |
