Grundfos SQ 2-35 N Submersible Pump – 96160412
by Grundfos
SKU 96160412
Original price
$936.99
-
Original price
$936.99
Original price
$936.99
$936.99
-
$936.99
Current price
$936.99
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos SQ 2-35 N is a 3" multi-stage submersible pump designed for domestic water supply, tank liquid transfer, irrigation, and environmental applications. It features “floating” impellers, each supported by a tungsten carbide/ceramic bearing for durability. The pump provides soft starting and integrated protection against dry-running, upthrust, overvoltage, undervoltage, overload, and overtemperature.
Suitable for:
- Domestic ground water intake
- Domestic water pressure boosting
- Ground water intake
- Submersible pumps
Specifications:
| Category | Details |
|---|---|
| Product |
Product name: SQ 2-35 N Product No: 96160412 EAN: 5700398875093 Pump No: 96080719 Motor No: 96160858 Model: C Valve: Pump with built-in non-return valve Sales region: Australia |
| Performance |
Rated flow: 2 m³/h Rated head: 35 m Stages: 2 Pump speed (data basis): 10700 rpm Curve tolerance: ISO9906:2012 3B |
| Liquid |
Pumped liquid: Water Liquid temperature range: 0 .. 35 °C Selected liquid temperature: 20 °C Density: 998.2 kg/m³ |
| Materials |
Pump: Stainless steel (EN 1.4401 / AISI 316) Impeller: Composite (ZYTEL 70G30 HSLR PA6.6-GF30) Motor: Stainless steel (DIN W.-Nr. 1.4401 / AISI 316) |
| Installation |
Maximum operating pressure: 15 bar Pump outlet: RP 1 1/4 Minimum borehole diameter: 76 mm |
| Electrical data |
Motor type: MS3 N Power input (P1): 1 kW Rated power (P2): 0.7 kW Power (P2) required by pump: 0.47 kW Mains frequency: 50 Hz Rated voltage: 1 x 200-240 V Rated current: 5.3 A Power factor: 1.00 Rated speed: 10700 rpm Start method: Direct-on-line Enclosure class: IP68 Insulation class: F Built-in motor protection: Yes Thermal protection: Internal Length of cable: 1.5 m Controls: CU 300 / CU 301 (no communication possible) |
| Approvals | CE, PCBC, RCM, EAC, CN Rohs Exempt, Morocco, UKCA, SEPRO |
| Weight & shipping |
Net weight: 4.7 kg Gross weight: 5.4 kg Shipping volume: 0.0092 m³ |
Documentation & Downloads:
| Document | Download |
|---|---|
| SQ, SQE (I & O instructions) | 📄 Download PDF |
| SQ, SQE, SQFlex (Safety instructions) | 📄 Download PDF |
| SQ, SQE, SQE-NE - submersible pumps (Data booklet) | 📄 Download PDF |
| SQ, SQE (Service Kit Catalogue) | 📄 Download PDF |
| SQ, SQE, SQ-N, MS 3 MSE 3, Model A (Service Instruction) | 📄 Download PDF |
| SQ, SQE, SQ-N Model B, MS 3, MSE 3 Model B (Service Instructions) | 📄 Download PDF |
