Multi-Level Float Trees (3 Float) 10m - FSW-12545
by Matelec
SKU FSW-12545
Original price
$436.48
-
Original price
$436.48
Original price
$436.48
$436.48
-
$436.48
Current price
$436.48
📢 For orders over $100, FREE Shipping Australia-wide
The Multi Float Tree is a unique combination of floats, configured in a way that minimises installation/setup time and overcomes the many issues associated with float switch installations.
Key Features
- Resin filled/potted connection - fully submersible
- Horizontal pivot point for switching accuracy and consistency
- Weighted, obviating flow induced travel - no more tangled floats
- No more setting up with conduits and ties
- No more trying to pull multiple float wires through undersized conduit
- No more trying to decipher which wires relate to which floats
Key Specifications
| Cable Length | 10m |
| Liquid Temperature | Min 0°C (32°F), Max 60°C (140°F) |
| Protection | IP68 |
| Maximum Depth | 9m (30ft) |
| Contact Type | Mechanically activated, snap action N/O contacts (close on rise) |
| Max Voltage | 250Vac 50/60Hz |
| Max Run Current | 6 Amps (resistive) |
| Cable Material | Floats - Neoprene rubber, Multicore - Polyvinyl chloride |
| Multicore Cable Size | ø8mm / 4 x 0.75mm² |
| Housing Material | Polypropylene |
Documentation & Downloads
| Multi Level Float Trees - 3 Float | Download |
