Grundfos CRN 5-9 A-CA-A-V-HQQV Vertical Multistage Centrifugal Pump – 96520808 (3 x 220-240D/380-415YV)

SKU 96520808
Original price $2,797.44 - Original price $2,797.44
Original price
$2,797.44
$2,797.44 - $2,797.44
Current price $2,797.44

📢 For orders over $100, FREE Shipping Australia-wide

The Grundfos CRN 5-9 A-CA-A-V-HQQV is a vertical, non-self-priming, multistage in-line centrifugal pump engineered for pipe system installation and foundation mounting. It features high-grade stainless steel wetted parts (EN 1.4401 / AISI 316), a HQQV cartridge shaft seal, FlexiClamp (CA) DN 32 connections, and a 3-phase IEC 90SD motor (1.5 kW). This pump is designed for industrial, commercial, agricultural, and water treatment applications where high efficiency, reliability, and durability are essential.

Suitable Applications

  • Commercial heating
  • Commercial air conditioning
  • Commercial water pressure boosting
  • Industrial water supply and process water treatment
  • Desalination and reverse osmosis systems
  • Water distribution, irrigation, and solar water solutions
  • Agriculture, livestock watering, fertigation, and solar boosting solutions

Key Specifications

Product Name CRN 5-9 A-CA-A-V-HQQV
Product Number 96520808
EAN 5700396832432
Pump Type Vertical Multistage Centrifugal
Rated Flow 5.8 m³/h
Rated Head 47.7 m
Maximum Head 63.9 m
Speed (Pump Data) 2896 rpm
Stages / Impellers 9 / 9
Shaft Seal HQQV
Liquid Temperature Range -20 .. 90 °C
Maximum Operating Pressure 25 bar
Connections DN 32 (1¼") inlet/outlet, FlexiClamp (CA), PN 25
Base / Head Material Stainless steel (EN 1.4408 / AISI 316)
Impeller Material Stainless steel (EN 1.4401 / AISI 316)
Bearing SIC
Motor Power (P2) 1.5 kW
Voltage 3 x 220-240D / 380-415Y V
Frequency 50 Hz
Rated Current 5.70 / 3.30 A
Motor Efficiency Class IE3
Motor Efficiency (Full Load) 84.2 %
Enclosure Class IP55
Insulation Class F
MEI ≥ 0.57
Net / Gross Weight 31.5 / 35.5 kg
Shipping Volume 0.092 m³
Approvals CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS

Documentation & Downloads

Grundfos CRN 5-9 A-CA-A-V-HQQV Datasheet Download
