Grundfos CRN 5-8 A-FGJ-A-V-HQQV Vertical Multistage Centrifugal Pump – 96517208 (3 x 220-240D/380-415YV)
by Grundfos
SKU 96517208
Original price
$2,556.81
-
Original price
$2,556.81
Original price
$2,556.81
$2,556.81
-
$2,556.81
Current price
$2,556.81
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CRN 5-8 A-FGJ-A-V-HQQV is a vertical, non-self-priming, inline multistage centrifugal pump designed for pipe system installation and foundation mounting. Constructed with high-grade stainless steel (EN 1.4401 / AISI 316) for all liquid-contacting components and a single HQQV shaft seal, the pump delivers 5.8 m³/h at a rated head of 40.3 m over 8 stages. It is powered by a 3-phase IEC 80C motor and features DIN / ANSI / JIS flange connections.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean
- Process liquids transfer
- Industrial heating
- Cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination
- Reversed Osmosis - Water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation
- Solar water solutions
- Community water supply
- Rotor & spray irrigation
- Ground water transfer
- Pivot
- Solar boosting and water supply solutions
- Controls and digital groundwater management
- Solar controls and digital water management
- Solar water treatment fertigation and dosing
- Agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Name | CRN 5-8 A-FGJ-A-V-HQQV |
| Product Number | 96517208 |
| EAN | 5700396758343 |
| Pump Type | Vertical Multistage Centrifugal |
| Rated Flow | 5.8 m³/h |
| Rated Head | 40.3 m |
| Maximum Head | 56.5 m |
| Speed (Pump Data) | 2853 rpm |
| Stages / Impellers | 8 / 8 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQV |
| Liquid Temperature Range | -20 .. 90 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 25/32, 1 1/4 inch, DIN / ANSI / JIS, PN 25, 300 lb |
| Flange Size for Motor | FT100 |
| Base / Head Material | Stainless steel (EN 1.4408 / AISI 316) |
| Impeller Material | Stainless steel (EN 1.4401 / AISI 316) |
| Bearing | SIC |
| Motor Power (P2) | 1.1 kW |
| Voltage | 3 x 220-240D/380-415Y V |
| Frequency | 50 Hz |
| Rated Current | 4.35 / 2.50 A |
| Motor Efficiency Class | IE3 |
| Motor Efficiency (Full Load) | 82.7 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.57 |
| Net / Gross Weight | 29.1 / 31.9 kg |
| Shipping Volume | 0.074 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| Product Datasheet | Download |
