Grundfos CRN 5-8 A-FGJ-A-V-HQQV Vertical Multistage Centrifugal Pump – 92902677 (1 x 220-230V)
by Grundfos
SKU 92902677
Original price
$2,884.75
-
Original price
$2,884.75
Original price
$2,884.75
$2,884.75
-
$2,884.75
Current price
$2,884.75
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CRN 5-8 A-FGJ-A-V-HQQV is a vertical multistage centrifugal inline pump engineered for industrial, commercial, and solar water applications. Made with high-grade stainless steel (EN 1.4401 / AISI 316) for all wetted parts, it delivers a rated flow of 5.8 m³/h and a rated head of 37.8 m, with a maximum head of 54 m. Equipped with a HQQV single cartridge shaft seal, combined DIN / ANSI / JIS flanged connections, and a 1.1 kW IEC 90SE 1-phase motor, it ensures reliable, energy-efficient operation.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean
- Process liquids transfer
- Industrial heating
- Cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination
- Reversed Osmosis - Water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation
- Solar water solutions
- Community water supply
- Rotor & spray irrigation
- Ground water transfer
- Pivot
- Solar boosting and water supply solutions
- Controls and digital groundwater management
- Solar controls and digital water management
- Solar water treatment fertigation and dosing
- Agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Name | CRN 5-8 A-FGJ-A-V-HQQV |
| Product Number | 92902677 |
| EAN | 5715121305280 |
| Pump Type | Vertical Multistage Centrifugal |
| Rated Flow | 5.8 m³/h |
| Rated Head | 37.8 m |
| Maximum Head | 54 m |
| Speed (Pump Data) | 2789 rpm |
| Stages / Impellers | 8 / 8 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQV |
| Liquid Temperature Range | -20 .. 90 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 25/32, 1 1/4 inch, DIN / ANSI / JIS, PN 25, 300 lb |
| Flange Size for Motor | FT115 |
| Base / Head Material | Stainless steel (EN 1.4408 / AISI 316) |
| Impeller Material | Stainless steel (EN 1.4401 / AISI 316) |
| Bearing | SIC |
| Motor Power (P2) | 1.1 kW |
| Voltage | 1 x 220-230 V |
| Frequency | 50 Hz |
| Rated Current | 6.60-6.30 A |
| Motor Efficiency Class | IE2 |
| Motor Efficiency (Full Load) | 79.6 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.57 |
| Net / Gross Weight | 36.1 / 38.8 kg |
| Shipping Volume | 0.104 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| Product Datasheet | Download |
