Grundfos CRN 5-5 A-FGJ-A-V-HQQV Vertical Multistage Centrifugal Pump – 92902673 (1 x 220-230V)
by Grundfos
SKU 92902673
Original price
$2,546.50
-
Original price
$2,546.50
Original price
$2,546.50
$2,546.50
-
$2,546.50
Current price
$2,546.50
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CRN 5-5 A-FGJ-A-V-HQQV is a vertical multistage centrifugal inline pump built for reliable pressure boosting, liquid transfer, and water treatment duties in commercial and industrial systems. Manufactured with high-grade stainless steel wetted components (EN 1.4401 / AISI 316), it delivers a rated flow of 5.8 m³/h and a rated head of 21.7 m, with a maximum head of 32 m. It features a dependable HQQV single cartridge shaft seal, combined DIN / ANSI / JIS flanged pipe connections, and a 0.75 kW 1-phase IEC motor with IE2 efficiency for efficient and long-term service performance.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean
- Process liquids transfer
- Industrial heating
- Cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination
- Reversed Osmosis - Water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation
- Solar water solutions
- Community water supply
- Rotor & spray irrigation
- Ground water transfer
- Pivot
- Solar boosting and water supply solutions
- Controls and digital groundwater management
- Solar controls and digital water management
- Solar water treatment fertigation and dosing
- Agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Name | CRN 5-5 A-FGJ-A-V-HQQV |
| Product Number | 92902673 |
| EAN | 5715121305204 |
| Pump Type | Vertical Multistage Centrifugal |
| Rated Flow | 5.8 m³/h |
| Rated Head | 21.7 m |
| Maximum Head | 32 m |
| Speed (Pump Data) | 2759 rpm |
| Stages / Impellers | 5 / 5 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQV |
| Liquid Temperature Range | -20 .. 90 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 25/32, 1 1/4 inch, DIN / ANSI / JIS, PN 25, 300 lb |
| Base / Head Material | Stainless steel (EN 1.4408 / AISI 316) |
| Impeller Material | Stainless steel (EN 1.4401 / AISI 316) |
| Bearing | SIC |
| Motor Power (P2) | 0.75 kW |
| Voltage | 1 x 220-230 V |
| Frequency | 50 Hz |
| Rated Current | 4.75-4.60 A |
| Motor Efficiency Class | IE2 |
| Motor Efficiency (Full Load) | 77.4 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.57 |
| Net / Gross Weight | 26.1 / 28.5 kg |
| Shipping Volume | 0.08 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| Product Datasheet | Download |
