Grundfos CRN 5-18 A-CA-A-V-HQQV Vertical Multistage Centrifugal Pump – 96532696 (3 x 220-240D/380-415YV)

SKU 96532696
Original price $3,981.31 - Original price $3,981.31
Original price
$3,981.31
$3,981.31 - $3,981.31
Current price $3,981.31

📢 For orders over $100, FREE Shipping Australia-wide

The Grundfos CRN 5-18 A-CA-A-V-HQQV is a vertical, non-self-priming, multistage in-line centrifugal pump designed for pipe system installation or foundation mounting. Constructed with high-grade stainless steel wetted parts (EN 1.4401 / AISI 316) and a HQQV cartridge shaft seal, it features FlexiClamp (CA) DN 32 connections and a 3-phase IEC 100LC motor (3 kW). Ideal for demanding commercial, industrial, agricultural, and water treatment applications, this pump provides high efficiency and reliable operation up to 122.7 m head.

Suitable Applications

  • Commercial heating and air conditioning
  • Commercial water pressure boosting
  • Industrial water supply, wastewater, and process water treatment
  • Desalination and reverse osmosis
  • Water distribution, irrigation, and solar water solutions
  • Agriculture, livestock watering, fertigation, and solar boosting solutions

Key Specifications

Product Name CRN 5-18 A-CA-A-V-HQQV
Product Number 96532696
EAN 5700397403792
Pump Type Vertical Multistage Centrifugal
Rated Flow 5.8 m³/h
Rated Head 93 m
Maximum Head 122.7 m
Speed (Pump Data) 2902 rpm
Stages / Impellers 18 / 18
Shaft Seal HQQV
Liquid Temperature Range -20 .. 90 °C
Maximum Operating Pressure 25 bar
Connections DN 32 (1¼") inlet/outlet, FlexiClamp (CA), PN 25
Base / Head Material Stainless steel (EN 1.4408 / AISI 316)
Impeller Material Stainless steel (EN 1.4401 / AISI 316)
Bearing SIC
Motor Power (P2) 3 kW
Voltage 3 x 220-240D / 380-415Y V
Frequency 50 Hz
Rated Current 11.0 / 6.30 A
Motor Efficiency Class IE3
Motor Efficiency (Full Load) 87.1 %
Enclosure Class IP55
Insulation Class F
Built-in Motor Protection PTC
MEI ≥ 0.57
Net / Gross Weight 45.9 / 48.8 kg
Shipping Volume 0.13 m³
Approvals CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS

Documentation & Downloads

Grundfos CRN 5-18 A-CA-A-V-HQQV Datasheet Download
