Grundfos CRN 20-8 A-FGJ-A-V-HQQV Vertical Multistage Centrifugal Pump – 96500658 (3 x 380-415D/660-690YD)
by Grundfos
SKU 96500658
Original price
$9,927.50
-
Original price
$9,927.50
Original price
$9,927.50
$9,927.50
-
$9,927.50
Current price
$9,927.50
📢 For orders over $100, FREE Shipping Australia-wide
A vertical, non-self-priming, multistage, in-line centrifugal pump designed for installation in pipe systems. The pump features a stainless steel construction (EN 1.4401/1.4408) for all wetted parts, ensuring high corrosion resistance. It delivers a rated flow of 21 m³/h and a rated head of 95.1 meters, with a maximum operating pressure of 25 bar. The shaft seal (type HQQV) follows EN 12756 standards, and pipe connections are available in DIN/ANSI/JIS flanges (DN 50, PN 25). Power transmission is provided by an 11 kW, IE3-rated, 3-phase AC motor with IP55 enclosure protection.
Suitable Applications
- Commercial heating and air conditioning
- Commercial and community water pressure boosting
- District heating and cooling
- Industrial heating, cooling, and water supply
- Industrial wastewater and process water treatment
- Desalination and reverse osmosis (water treatment)
- Drinking water treatment and water distribution
- Irrigation (rotor & spray, pivot, ground water transfer)
- Solar water solutions (boosting, fertigation, dosing, livestock watering)
- Surface water intake and groundwater management
Key Specifications
| Product Name | CRN 20-8 A-FGJ-A-V-HQQV |
| Product Number | 96500658 |
| EAN | 5700396206226 |
| Pump Type | Vertical, Multistage Centrifugal |
| Rated Flow | 21 m³/h |
| Rated Head | 95.1 m |
| Maximum Head | 118 m |
| Speed (Pump Data) | 2924 rpm |
| Stages / Impellers | 8 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQV (Single, EN 12756) |
| Liquid Temperature Range | -20 .. 90 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 50 (2 inch) / DIN / ANSI / JIS / PN 25 / 300 lb |
| Base / Head Material | Stainless Steel (EN 1.4408 / AISI 316) |
| Impeller Material | Stainless Steel (EN 1.4401 / AISI 316) |
| Bearing | SIC |
| Motor Power (P2) | 11 kW |
| Voltage | 3 x 380-415D / 660-690Y V |
| Frequency | 50 Hz |
| Rated Current | 20.8-19.8 / 12.0-11.8 A |
| Motor Efficiency Class | IE3 |
| Motor Efficiency (Full Load) | 91.2 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.70 |
| Net / Gross Weight | 143 kg / 171 kg |
| Shipping Volume | 0.488 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, WRAS, ACS |
Documentation & Downloads
| Product Datasheet – CRN 20-8 A-FGJ-A-V-HQQV (96500658) | Download |
