Grundfos CRN 20-1 A-FGJ-A-V-HQQV Vertical Multistage Centrifugal Pump – 96500484 (3 x 220-240D/380-415YV)
by Grundfos
SKU 96500484
Original price
$3,385.25
-
Original price
$3,385.25
Original price
$3,385.25
$3,385.25
-
$3,385.25
Current price
$3,385.25
📢 For orders over $100, FREE Shipping Australia-wide
Grundfos CRN 20-1 A-FGJ-A-V-HQQV is a vertical multistage centrifugal pump designed for efficient water transfer and pressure boosting in commercial, industrial, and water treatment systems. Constructed with high-grade stainless steel wetted parts (EN 1.4401 / EN 1.4408, AISI 316), it delivers a rated flow of 21 m³/h and a rated head of 9.9 m, with a maximum head of 14 m. The pump features a single HQQV shaft seal, FGJ DIN / ANSI / JIS flange connections (DN 50), and is driven by a 1.1 kW IEC 3-phase motor, ensuring reliable and durable performance.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating and cooling
- Industrial water supply
- Industrial wastewater and process water treatment
- Desalination and reverse osmosis systems
- Wash and clean systems
- Process liquids transfer
- Water distribution and irrigation
- Surface water intake and groundwater transfer
- Drinking water treatment
- Agricultural irrigation and fertigation
- Livestock watering and community water supply
- Solar water supply and boosting solutions
Key Specifications
| Product Name | CRN 20-1 A-FGJ-A-V-HQQV |
| Product Number | 96500484 |
| EAN | 5700396202747 |
| Pump Type | Vertical Multistage Centrifugal |
| Rated Flow | 21 m³/h |
| Rated Head | 9.9 m |
| Maximum Head | 14 m |
| Speed (Pump Data) | 2853 rpm |
| Stages / Impellers | 2 / 1 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQV |
| Liquid Temperature Range | -20 .. 90 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 50 / DN 50, DIN / ANSI / JIS, PN 25, 300 lb flange |
| Base / Head Material | Stainless steel (EN 1.4408 / AISI 316) |
| Impeller Material | Stainless steel (EN 1.4401 / AISI 316) |
| Bearing | SIC |
| Motor Power (P2) | 1.1 kW |
| Voltage | 3 x 230-255D/400-440Y V |
| Frequency | 50 Hz |
| Rated Current | 4.10-4.00 / 2.38-2.30 A |
| Motor Efficiency Class | NEMA Premium / IE3 (60Hz) |
| Motor Efficiency (Full Load) | 84.0 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.70 |
| Net / Gross Weight | 39 kg / 52 kg |
| Shipping Volume | 0.173 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| Product Datasheet / PDF | Download |
