Grundfos CRN 1S-4 A-FGJ-A-V-HQQV Vertical Multistage Centrifugal Pump – 92900118 (1 x 220-230V)
by Grundfos
SKU 92900118
Original price
$1,957.31
-
Original price
$1,957.31
Original price
$1,957.31
$1,957.31
-
$1,957.31
Current price
$1,957.31
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CRN 1S-4 A-FGJ-A-V-HQQV is a vertical multistage centrifugal inline pump engineered for reliable pressure boosting and water transfer in commercial, industrial, and agricultural applications. All wetted components are manufactured from high-grade stainless steel (EN 1.4401 / AISI 316) providing excellent corrosion resistance and long service life. The pump delivers a rated flow of 0.9 m³/h with a rated head of 19 m and a maximum head of 24.2 m. It features a HQQV single mechanical shaft seal and combined DIN / ANSI / JIS flange connections rated PN25 (300 lb). The pump is driven by a 0.37 kW single-phase IEC asynchronous motor with IP55 enclosure and IE2 efficiency class.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Industrial cleaning processes
- Process liquids transfer
- Industrial heating
- Industrial cooling
- Industrial water supply and transfer
- Industrial wastewater treatment and reuse
- Industrial process water treatment
- Desalination
- Reverse osmosis
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation systems
- Solar water solutions
- Community water supply
- Rotor and spray irrigation
- Groundwater transfer
- Livestock and wildlife watering
- Water treatment fertigation, chemigation and dosing
- Pivot and lateral irrigation
- Frost protection
- Solar boosting and water supply solutions
- Solar water treatment fertigation and dosing
- Municipal solar solutions
- Agriculture solar solutions
- Livestock watering with solar solutions
- Community solar solutions
Key Specifications
| Product Name | CRN 1S-4 A-FGJ-A-V-HQQV |
| Product Number | 92900118 |
| EAN | 5715121263955 |
| Pump Type | Vertical Multistage Centrifugal |
| Rated Flow | 0.9 m³/h |
| Rated Head | 19 m |
| Maximum Head | 24.2 m |
| Speed (Pump Data) | 2757 rpm |
| Stages / Impellers | 4 / 4 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQV |
| Liquid Temperature Range | -20 .. 90 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 25/32 (1 1/4") DIN / ANSI / JIS Flanges, PN25, 300 lb |
| Base / Head Material | Stainless Steel EN 1.4408 / AISI 316 |
| Impeller Material | Stainless Steel EN 1.4401 / AISI 316 |
| Bearing | SIC |
| Motor Power (P2) | 0.37 kW |
| Voltage | 1 x 220–230 V |
| Frequency | 50 Hz |
| Rated Current | 2.60–2.50 A |
| Motor Efficiency Class | IE2 |
| Motor Efficiency (Full Load) | 69.5 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.54 |
| Net / Gross Weight | 24 kg / 26.4 kg |
| Shipping Volume | 0.08 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| Grundfos CRN 1S-4 Product Datasheet | Download |
