Grundfos CRN 1S-27 A-FGJ-A-V-HQQV Vertical Multistage Centrifugal Pump – 92900211 (1 x 220-230V)
by Grundfos
SKU 92900211
Original price
$3,781.25
-
Original price
$3,781.25
Original price
$3,781.25
$3,781.25
-
$3,781.25
Current price
$3,781.25
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CRN 1S-27 A-FGJ-A-V-HQQV is a vertical inline multistage centrifugal pump designed for demanding water applications, including industrial processes, irrigation, solar water solutions, and drinking water systems. It features high-grade stainless steel (EN 1.4401 / AISI 316) wetted parts, a rigid split coupling, and combined DIN/ANSI/JIS flange connections. The pump delivers a rated flow of 0.9 m³/h with a rated head of 119.4 m and a maximum head of 159.1 m. It is equipped with a single HQQV mechanical shaft seal and a 1.1 kW single-phase IEC 90SE motor with IP55 protection for efficient, reliable operation.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean
- Process liquids transfer
- Industrial heating and cooling
- Industrial water supply
- Industrial wastewater treatment
- Industrial process water treatment
- Desalination
- Reverse osmosis water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation systems
- Solar water solutions
- Community water supply
- Rotor and spray irrigation
- Groundwater transfer
- Pivot irrigation
- Solar boosting and water supply solutions
- Solar controls and digital water management
- Solar water treatment, fertigation and dosing
- Agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Name | CRN 1S-27 A-FGJ-A-V-HQQV |
| Product Number | 92900211 |
| EAN | 5715121265652 |
| Pump Type | Vertical Multistage Centrifugal |
| Rated Flow | 0.9 m³/h |
| Rated Head | 119.4 m |
| Maximum Head | 159.1 m |
| Pump Speed | 2789 rpm |
| Stages / Impellers | 27 / 27 |
| Shaft Seal | HQQV |
| Liquid Temperature Range | -20 .. 90 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 25/32 (1 1/4") DIN / ANSI / JIS Flanges, PN25, 300 lb |
| Base Material | Stainless Steel EN 1.4408 / AISI 316 |
| Impeller Material | Stainless Steel EN 1.4401 / AISI 316 |
| Bearing | SIC |
| Motor Power (P2) | 1.1 kW |
| Voltage | 1 x 220–230 V |
| Frequency | 50 Hz |
| Rated Current | 6.30–6.60 A |
| Motor Efficiency Class | IE2 |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.54 |
| Net Weight | 42.3 kg |
| Gross Weight | 45.2 kg |
| Shipping Volume | 0.13 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| Grundfos CRN 1S-27 Product Datasheet | Download PDF |
