Grundfos CRN 1S-13 A-FGJ-A-V-HQQV Vertical Multistage Centrifugal Pump – 92900140 (1 x 220-230V)
by Grundfos
SKU 92900140
Original price
$2,479.13
-
Original price
$2,479.13
Original price
$2,479.13
$2,479.13
-
$2,479.13
Current price
$2,479.13
📢 For orders over $100, FREE Shipping Australia-wide
The Grundfos CRN 1S-13 A-FGJ-A-V-HQQV is a vertical inline multistage centrifugal pump engineered for high-pressure water supply, industrial, and irrigation applications. Wetted components are constructed from high-grade stainless steel (EN 1.4401 / AISI 316) for corrosion resistance and durability. It delivers a rated flow of 0.9 m³/h with a rated head of 53.4 m and a maximum head of 73.8 m. The pump includes a single HQQV mechanical shaft seal, DIN / ANSI / JIS flange connections (PN25, 300 lb), and a 0.37 kW single-phase IEC asynchronous motor with IP55 protection and IE2 efficiency.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean
- Process liquids transfer
- Industrial heating and cooling
- Industrial water supply
- Industrial wastewater treatment
- Industrial process water treatment
- Desalination
- Reverse osmosis water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation systems
- Solar water solutions
- Community water supply
- Rotor and spray irrigation
- Groundwater transfer
- Pivot irrigation
- Solar boosting and water supply solutions
- Solar water treatment, fertigation and dosing
- Agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Name | CRN 1S-13 A-FGJ-A-V-HQQV |
| Product Number | 92900140 |
| EAN | 5715121264167 |
| Pump Type | Vertical Multistage Centrifugal |
| Rated Flow | 0.9 m³/h |
| Rated Head | 53.4 m |
| Maximum Head | 73.8 m |
| Pump Speed | 2757 rpm |
| Stages / Impellers | 13 / 13 |
| Shaft Seal | HQQV |
| Liquid Temperature Range | -20 .. 90 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 25/32 (1 1/4") DIN / ANSI / JIS Flanges, PN25, 300 lb |
| Base Material | Stainless Steel EN 1.4408 / AISI 316 |
| Impeller Material | Stainless Steel EN 1.4401 / AISI 316 |
| Bearing | SIC |
| Motor Power (P2) | 0.37 kW |
| Voltage | 1 x 220–230 V |
| Frequency | 50 Hz |
| Rated Current | 2.60–2.50 A |
| Motor Efficiency Class | IE2 |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.54 |
| Net Weight | 27.6 kg |
| Gross Weight | 30.2 kg |
| Shipping Volume | 0.094 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| Grundfos CRN 1S-13 Product Datasheet | Download PDF |
