Grundfos CRI 1-4 A-CA-A-E-HQQE Vertical Multistage Centrifugal Pump – 96516318 (3 x 220-240D/380-415YV)
by Grundfos
SKU 96516318
Original price
$1,042.25
-
Original price
$1,042.25
Original price
$1,042.25
$1,042.25
-
$1,042.25
Current price
$1,042.25
📢 For orders over $100, FREE Shipping Australia-wide
Vertical, non-self-priming, multistage in-line centrifugal pump for installation in pipe systems or on a foundation. Liquid-contacting parts—including impellers, intermediate chambers, and outer sleeve—are stainless steel EN 1.4301, with pump head cover and base in stainless steel EN 1.4408 / AISI 316. Single HQQE shaft seal per EN 12756, DN 32 (1¼ inch) FlexiClamp connections rated PN 25, and a 3-phase AC motor (0.37 kW, P2) with IE3 efficiency class make it suitable for commercial, industrial, and solar water applications.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean
- Process liquids transfer
- Industrial heating
- Cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination
- Reversed Osmosis - Water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation
- Solar water solutions
- Community water supply
- Rotor & spray irrigation
- Ground water transfer
- Pivot irrigation
- Solar boosting and water supply solutions
- Controls and digital groundwater management
- Solar controls and digital water management
- Solar water treatment fertigation and dosing
- Agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Name | CRI 1-4 A-CA-A-E-HQQE |
| Product Number | 96516318 |
| EAN | 5700396740812 |
| Pump Type | Vertical Multistage Centrifugal |
| Rated Flow | 1.8 m³/h |
| Rated Head | 20.3 m |
| Maximum Head | 25.4 m |
| Speed (Pump Data) | 2873 rpm |
| Stages / Impellers | 4 / 4 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQE |
| Liquid Temperature Range | -20 .. 120 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 32 (1¼ inch) FlexiClamp, PN 25 |
| Base / Head Material | Stainless Steel EN 1.4408 / AISI 316 |
| Impeller Material | Stainless Steel EN 1.4301 / AISI 304 |
| Bearing | SIC |
| Motor Power (P2) | 0.37 kW |
| Voltage | 3 × 220–240D / 380–415Y V |
| Frequency | 50 Hz |
| Rated Current | 1.74 / 1.00 A |
| Motor Efficiency Class | IE3 |
| Motor Efficiency (Full Load) | 73.8 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | ≥ 0.70 |
| Net / Gross Weight | 17.1 kg / 19.7 kg |
| Shipping Volume | 0.054 m³ |
| Approvals | CE, EAC, UKCA, SEPRO, RCM, WRAS, ACS |
Documentation & Downloads
| Product Datasheet | Download |
