Grundfos UPS 25-60 180 Circulator Pump – 1½" Connection – 96281483

Name: Grundfos UPS 25-60 180 Circulator Pump – 1½" Connection – 96281483
Brand: Grundfos
SKU: 96281483
Price: 355.0 AUD
Availability: InStock

by Grundfos

SKU 96281483

$355.00 - $355.00

$355.00

$355.00 - $355.00

$355.00

📢 For orders over $100, FREE Shipping Australia-wide

The Grundfos UPS 25-60 180 is a three-speed circulator pump for commercial and domestic heating systems, as well as hot water re-circulation in domestic buildings. Its canned-rotor design ensures maintenance-free operation, with bearings lubricated by the pumped liquid. The pump’s robust cast-iron and composite construction provides long-lasting reliability without requiring additional motor protection.

Key Features:

Three-speed pump selector for flexible system operation
Canned-rotor type – pump and motor form an integral unit
Ceramic shaft and radial bearings with carbon axial bearing
Stainless steel rotor can and bearing plate
Corrosion-resistant composite impeller (PES+30% GF)
Cast iron pump housing (EN-GJL-150)
Terminal box positioned at 9H
Impedance-protected thermal protection

Key Specifications:

Product Model	UPS 25-60 180
Product Number	96281483
Pump Type	Three-speed circulator
Connection Size	1½ inch
Port-to-Port Length	180 mm
Rated Flow	2.17 m³/h
Rated Head	3.17 m
Maximum Head	60 dm
TF Class	110
Pumped Liquid	Water
Liquid Temperature Range	2 – 110 °C
Selected Liquid Temperature	60 °C
Density	983.2 kg/m³
Maximum Operating Pressure	10 bar
Ambient Temperature Range	0 – 40 °C
Power Input (Speed 1)	50 W
Power Input (Speed 2)	55 W
Maximum Power Input	60 W
Current (Speed 1)	0.21 A
Current (Speed 2)	0.25 A
Current (Speed 3)	0.28 A
Capacitor Size	2.5 µF
Enclosure Class	IP44
Insulation Class	F
Ex-Protection Standard	NONE
Pump Housing	Cast iron, EN 1561 EN-GJL-150, ASTM 30B
Impeller	Composite, PES+30% GF
Terminal Box Position	9H
Net Weight	2.67 kg
Gross Weight	2.8 kg
Shipping Volume	0.004 m³
Approvals	VDE, AAA, EAC, RCM
Country of Origin	DK

Quantity

Key Features:

Three-speed pump selector for flexible system operation
Canned-rotor type – pump and motor form an integral unit
Ceramic shaft and radial bearings with carbon axial bearing
Stainless steel rotor can and bearing plate
Corrosion-resistant composite impeller (PES+30% GF)
Cast iron pump housing (EN-GJL-150)
Terminal box positioned at 9H
Impedance-protected thermal protection

Key Specifications:

Product Model	UPS 25-60 180
Product Number	96281483
Pump Type	Three-speed circulator
Connection Size	1½ inch
Port-to-Port Length	180 mm
Rated Flow	2.17 m³/h
Rated Head	3.17 m
Maximum Head	60 dm
TF Class	110
Pumped Liquid	Water
Liquid Temperature Range	2 – 110 °C
Selected Liquid Temperature	60 °C
Density	983.2 kg/m³
Maximum Operating Pressure	10 bar
Ambient Temperature Range	0 – 40 °C
Power Input (Speed 1)	50 W
Power Input (Speed 2)	55 W
Maximum Power Input	60 W
Current (Speed 1)	0.21 A
Current (Speed 2)	0.25 A
Current (Speed 3)	0.28 A
Capacitor Size	2.5 µF
Enclosure Class	IP44
Insulation Class	F
Ex-Protection Standard	NONE
Pump Housing	Cast iron, EN 1561 EN-GJL-150, ASTM 30B
Impeller	Composite, PES+30% GF
Terminal Box Position	9H
Net Weight	2.67 kg
Gross Weight	2.8 kg
Shipping Volume	0.004 m³
Approvals	VDE, AAA, EAC, RCM
Country of Origin	DK
