Grundfos CR 45-7 A-F-A-E-HQQE Vertical Multistage Centrifugal Pump – 96122809 (3 x 380-420D/660-725Y)
by Grundfos
SKU 96122809
Original price
$13,472.25
-
Original price
$13,472.25
Original price
$13,472.25
$13,472.25
-
$13,472.25
Current price
$13,472.25
📢 For orders over $100, FREE Shipping Australia-wide
Vertical, non-self-priming, multistage in-line centrifugal pump designed for installation in pipe systems and foundation mounting. The pump head and base are constructed from cast iron, while all wetted parts are stainless steel (EN 1.4301) for corrosion resistance. Equipped with a single HQQE shaft seal (EN 12756), DIN flanged DN 80 connections (PN 40), and a high-efficiency IE3 3-phase AC motor rated at 30 kW, making it suitable for high-pressure industrial and water supply applications.
Suitable Applications
- Commercial heating
- Commercial air conditioning
- Commercial water pressure boosting
- District heating
- District cooling
- Machining
- Wash and clean
- Process liquids transfer
- Industrial heating
- Cooling
- Industrial water supply
- Industrial wastewater
- Industrial process water treatment
- Desalination
- Reversed Osmosis - Water treatment
- Surface water intake
- Drinking water treatment
- Water distribution
- Irrigation
- Solar water solutions
- Community water supply
- Rotor & spray irrigation
- Ground water transfer
- Pivot
- Solar boosting and water supply solutions
- Controls and digital groundwater management
- Solar controls and digital water management
- Solar water treatment fertigation and dosing
- Agriculture solar solutions
- Livestock watering with solar solutions
Key Specifications
| Product Name | CR 45-7 A-F-A-E-HQQE |
| Product Number | 96122809 |
| EAN | 5700396688534 |
| Pump Type | Vertical / Multistage Centrifugal |
| Rated Flow | 45 m³/h |
| Rated Head | 143.9 m |
| Maximum Head | 179.4 m |
| Speed (Pump Data) | 2951 rpm |
| Stages / Impellers | 7 / 7 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | HQQE |
| Liquid Temperature Range | -30 .. 120 °C |
| Maximum Operating Pressure | 30 bar |
| Connections | DN 80 / DN 80, DIN flanges, PN 40 |
| Base / Head Material | Cast iron |
| Impeller Material | Stainless steel EN 1.4301 / AISI 304 |
| Bearing | SIC / Graflon |
| Motor Power (P2) | 30 kW |
| Voltage | 3 x 380-420D/660-725Y V |
| Frequency | 50 Hz |
| Rated Current | 53 / 31 A |
| Motor Efficiency Class | IE3 |
| Motor Efficiency (Full Load) | 93.3 % |
| Enclosure Class | IP55 |
| Insulation Class | F |
| MEI | 0.70 |
| Net / Gross Weight | 324 / 362 kg |
| Shipping Volume | 0.805 m³ |
| Approvals | CE, EAC, UKCA, WRAS, ACS |
Documentation & Downloads
| Product PDF | Download |
