Grundfos CR 3-10 A-A-A-E-HQQE Vertical Multistage Pump – 92901494 (1 x 220-230V)
by Grundfos
SKU 92901494
Original price
$1,436.19
-
Original price
$1,436.19
Original price
$1,436.19
$1,436.19
-
$1,436.19
Current price
$1,436.19
📢 For orders over $100, FREE Shipping Australia-wide
Vertical, multistage centrifugal pump with inlet and outlet ports on the same level (inline). The pump head and base are in cast iron – all other wetted parts are in stainless steel. A cartridge shaft seal ensures high reliability, safe handling, and easy access and service. Power transmission is via a rigid split coupling. The pump is fitted with a 1-phase, fan-cooled asynchronous motor. Suitable for a wide range of applications including commercial heating, water pressure boosting, industrial process water treatment, irrigation, solar water solutions, and more.
Key Features:
- Vertical, multistage centrifugal pump with inline inlet and outlet
- Pump head and base in cast iron; all wetted parts in stainless steel (EN 1.4301)
- Cartridge shaft seal for high reliability and easy service
- Rigid split coupling for power transmission
- 1-phase, fan-cooled asynchronous motor
- CE, EAC, UKCA, SEPRO, RCM approvals; WRAS & ACS for drinking water
- Wide application: commercial, industrial, agricultural, and solar solutions
Technical Specifications:
| Model | CR 3-10 A-A-A-E-HQQE |
| SKU | 92901494 |
| Pumped liquid | Water |
| Liquid temperature range | -20 .. 120 °C |
| Rated flow | 3 m³/h |
| Rated head | 43.6 m |
| Maximum head | 63.9 m |
| Stages | 10 |
| Impellers | 10 |
| Pump orientation | Vertical |
| Shaft seal arrangement | Single (HQQE) |
| Motor power (P2) | 0.75 kW |
| Voltage | 1 x 220-230 V |
| Frequency | 50 Hz |
| Net weight | 24.6 kg |
| Gross weight | 27.4 kg |
Documentation & Downloads:
| Document Name | Download Link |
|---|---|
| Grundfos Product PDF | 📄 Download PDF |
