Grundfos UNILIFT AP50.50.08.A1V Single phase with float switch and Vortex impeller
by Grundfos
SKU 96023934
Original price
$1,345.00
-
Original price
$1,345.00
Original price
$1,345.00
$1,345.00
-
$1,345.00
Current price
$1,345.00
📢 For orders over $100, FREE Shipping Australia-wide
Grundfos UNILIFT AP50.50.08.A1V
The Grundfos UNILIFT AP 35 and AP 50 are heavy duty, submersible pumps constructed from stainless steel, making them ideal for handling dirty stormwater runoff, domestic wastewater from bathroom basins or showers and fibrous laundry wastewater.
Features
- Highly corrosion resistant - Constructed of high quality industrial grade components. All parts in contact with the pumped liquid are made from 304 stainless steel
- Handles very dirty water with ease - Can both easily pump large particles in storm water run off or material fibres in laundry grey water
- Suitable for fully or partially submerged use - Come with an integrated motor cooling jacket, allowing the pump to operate for extended periods whilst only partly submerged
- Float switch options - Available with or without float switch to suit different installation configurations
- Permanent or portable use - The UNILIFT AP35 and 50 can be used in either a permanent installation or as a portable drainage pump
- Easy submerged installation – plug & pump - Connect the pump outlet to the pipework, plug into a power outlet and you’re ready to pump
Liquid temperature: 0°C to +55°C
Impeller type: Vortex
Max. particle size: Diam 35 mm for AP35 and Diam 50 mm for AP50
Supply voltage: 1 x 230 V 50Hz
Enclosure class: Suitable for submerged installation (IP68)
Scope of delivery: 10 m cable with plug
Versions:
A1V single phase with float switch and Vortex impeller
| Product Name | UNILIFT AP50.50.08.A1V |
| Product No | 96023934 |
| EAN Number | 5700390549138 |
| Suitable for | Commercial wastewater, Domestic wastewater |
| Maximum Flow | 6.94 l/s |
| Maximum Head | 9 m |
| Impeller Type | VORTEX |
| Max. Particle | 50 mm |
| Approvals | CE, RCM, LGABG, EAC, TUVRHWID |
| Pump Housing | Stainless steel, EN 1.4301, AISI 304 |
| Impeller Material | Stainless steel, EN 1.4301, AISI 304 |
| Cable Union | Brass, CW602N, C35330 |
| Type of Connection | Rp |
| Connection Size | 2 inch |
| Maximum Installation Depth | 7 m |
| Installation Place | Indoor / outdoor |
| Ambient Temperature Range | 0 .. 55 °C |
| Liquid Temperature Range | 0 .. 55 °C |
| Selected Liquid Temperature | 20 °C |
| Density | 998.2 kg/m³ |
| Power Input P1 | 1.3 kW |
| Motor Type | 1-phase, PSC |
| Rated Power P2 | 0.8 kW |
| Mains Frequency | 50 Hz |
| Rated Voltage | 1 × 220-240 V |
| Rated Current | 5.9 A |
| Power Factor (Cos φ) | 0.99 |
| Rated Speed | 2790 rpm |
| Capacitor Size - Run | 16 µF / 400 V |
| Enclosure Class (IEC 34-5) | IP68 |
| Insulation Class (IEC 85) | F |
| Built-in Motor Protection | CONTACT |
| Thermal Protection | Internal |
| Power Cable Length | 10 m |
| Cable Plug Type | AU |
| Controls | Level switch A |
| Net Weight | 15.6 kg |
| Gross Weight | 16.5 kg |
| Sales Region | Australia |
| Environmental Approvals | WEEE |
