Grundfos Unilift CC5 - A1 Submersible Pumps
Grundfos Unilift CC5 - A1
The Grundfos UNILIFT CC is a lightweight single-stage drainage pump with a semi-open impeller. They are designed for pumping drain water and grey wastewater containing particles up to 10 mm Diam.
UNILIFT CC can pump down to a water level of 3 mm above the floor by removing the strainer and can be used in permanent installations or as a portable pump.
Features
- Able to pump down to just 3 mm of water - Can pump down to a water level of just 3 mm after removing the strainer, making it perfect for draining pools, ponds or tanks for maintenance
- Suitable for fully or partially submerged use - Comes with an integrated motor cooling jacket, allowing the pump to operate for extended periods whilst only partially submerged
- High quality - Constructed of corrosion resistant composite and stainless steel components inside and out
- Light weight - At a weight of no more than 7 kg, the UNILIFT CC can be used in either a permanent installation or as a portable drainage pump
- Easy submerged installation – plug & pump - Connect the pump outlet to the pipework, plug into a power outlet and you’re ready to pump
Liquid temperature: +4°C to +40°C, 70°C for maximum 2 min, with at least 30 min intervals
Impeller type: Semi-open
Max. particle size: Diam 10 mm
Supply voltage: 1 x 220-240 Volt 50 Hz
Enclosure class: Suitable for submerged installation (IP68)
Pump outlets: 2 outlet choices: at the top or on side (multiple thread sizes -
Male 3/4" / 1" / 1-1 1/4" & Female 1-1 1/4")
Cable length: 10 m cable with plug
