Grundfos CR 95-8-2 A-F-A-E-HQQE Vertical Multistage Centrifugal Pump – 99748828 (3 x 380-420D/660YV)
by Grundfos
SKU 99748828
Original price
$22,386.38
-
Original price
$22,386.38
Original price
$22,386.38
$22,386.38
-
$22,386.38
Current price
$22,386.38
📢 For orders over $100, FREE Shipping Australia-wide
The CR 95-8-2 A-F-A-E-HQQE is a high-performance vertical multistage inline centrifugal pump designed for demanding water transfer, pressure boosting, and industrial circulation applications. It features inline suction and discharge ports, a ductile cast iron pump head and base, and stainless steel (EN 1.4301 / AISI 304) wetted components. The pump uses a reliable HQQE cartridge shaft seal, rigid split coupling, DIN flange connections, and a three-phase, fan-cooled asynchronous motor, providing safe operation, excellent efficiency, and simplified maintenance.
Suitable Applications
- Commercial heating and air conditioning
- Commercial water pressure boosting
- District heating and cooling
- Industrial water supply and wastewater handling
- Industrial process water treatment
- Desalination and reverse osmosis
- Drinking water treatment and distribution
- Surface water intake systems
- Process liquids transfer
- Machining, wash, and cleaning systems
- Irrigation and agricultural water supply
- Community water supply systems
- Groundwater transfer
- Rotor, spray, and pivot irrigation
- Solar water supply and boosting solutions
- Livestock watering and agriculture solar applications
Key Specifications
| Product Name | CR 95-8-2 A-F-A-E-HQQE |
| Product Number | 99748828 |
| EAN | 5713833739102 |
| Pump Type | Vertical multistage centrifugal (inline) |
| Rated Flow | 95 m³/h |
| Rated Head | 175.3 m |
| Maximum Head | 235.3 m |
| Speed (Pump Data) | 2975 rpm |
| Stages / Impellers | 8 / 8 |
| Reduced-Diameter Impellers | 2 |
| Shaft Seal | Single cartridge seal (HQQE) |
| Liquid Temperature Range | -20 to 120 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 100 / DN 100, DIN flanges, PN 25/40 |
| Base / Head Material | Ductile cast iron EN-GJS-500-7 |
| Impeller Material | Stainless steel EN 1.4301 (AISI 304) |
| Bearing | WC/WC with Graflon support bearing |
| Motor Power (P2) | 55 kW |
| Voltage | 3 × 380–420D / 660Y V |
| Frequency | 50 Hz |
| Rated Current | 96.85–87.6 / 55.8 A |
| Motor Efficiency Class | IE3 |
| Motor Efficiency (Full Load) | 94.3 % |
| Enclosure Class | IP55 (Protects against dust and water jets) |
| Insulation Class | F |
| MEI | ≥ 0.70 |
| Net / Gross Weight | 593 / 775 kg |
| Shipping Volume | 2.91 m³ |
| Approvals | CE, UKCA, SEPRO, ACS |
| Country of Origin | SG |
Documentation & Downloads
| Product Datasheet — CR 95-8-2 A-F-A-E-HQQE | Download |
