Grundfos CR 95-6 A-F-A-E-HQQE Vertical Multistage Centrifugal Pump – 99744904 (3 x 380-420D/660YV)
by Grundfos
SKU 99744904
Original price
$17,378.63
-
Original price
$17,378.63
Original price
$17,378.63
$17,378.63
-
$17,378.63
Current price
$17,378.63
📢 For orders over $100, FREE Shipping Australia-wide
The CR 95-6 A-F-A-E-HQQE is a high-performance vertical multistage inline centrifugal pump designed for demanding water transfer, pressure boosting, and industrial circulation applications. It features suction and discharge ports on the same level for inline installation, with a ductile cast iron pump head and base and stainless steel (EN 1.4301 / AISI 304) wetted components. Equipped with a reliable HQQE cartridge shaft seal, rigid split coupling, DIN flange connections, and a three-phase, fan-cooled asynchronous motor, it ensures safe handling, high efficiency, and easy maintenance.
Suitable Applications
- Commercial heating and air conditioning
- Commercial water pressure boosting
- District heating and cooling
- Industrial water supply and wastewater handling
- Industrial process water treatment
- Desalination and reverse osmosis
- Drinking water treatment and distribution
- Surface water intake systems
- Process liquids transfer
- Machining, wash, and cleaning systems
- Irrigation and agricultural water supply
- Community water supply systems
- Groundwater transfer
- Rotor, spray, and pivot irrigation
- Solar water supply and boosting solutions
- Livestock watering and agriculture solar applications
Key Specifications
| Product Name | CR 95-6 A-F-A-E-HQQE |
| Product Number | 99744904 |
| EAN | 5713833686475 |
| Pump Type | Vertical multistage centrifugal (inline) |
| Rated Flow | 95 m³/h |
| Rated Head | 140.3 m |
| Maximum Head | 186.3 m |
| Speed (Pump Data) | 2966 rpm |
| Stages / Impellers | 6 / 6 |
| Reduced-Diameter Impellers | 0 |
| Shaft Seal | Single cartridge seal (HQQE) |
| Liquid Temperature Range | -20 to 120 °C |
| Maximum Operating Pressure | 25 bar |
| Connections | DN 100 / DN 100, DIN flanges, PN 25/40 |
| Base / Head Material | Ductile cast iron EN-GJS-500-7 |
| Impeller Material | Stainless steel EN 1.4301 (AISI 304) |
| Bearing | WC/WC with Graflon support bearing |
| Motor Power (P2) | 45 kW |
| Voltage | 3 × 380–420D / 660Y V |
| Frequency | 50 Hz |
| Rated Current | 79.93–72.3 / 46.0 A |
| Motor Efficiency Class | IE3 |
| Motor Efficiency (Full Load) | 94.0 % |
| Enclosure Class | IP55 (Protects against dust and water jets) |
| Insulation Class | F |
| MEI | ≥ 0.70 |
| Net / Gross Weight | 428 / 574 kg |
| Shipping Volume | 2.04 m³ |
| Approvals | CE, UKCA, SEPRO, ACS |
| Country of Origin | SG |
Documentation & Downloads
| Product Datasheet — CR 95-6 A-F-A-E-HQQE | Download |
