Grundfos SEV.80.80.11.4.50B - 415volt- Super Vortex pump 96048486

The Grundfos SE1 pumps are designed for handling wastewater, process water and unscreened raw sewage in heavy-duty municipal, utility and industrial applications.

Pumped liquid : pH value : 4-10
Liquid temperature : 0°C to + 40°C
Impeller types : SuperVortex
Cable length : Standard 15 m (SEV.50.65 standard is 10 m) - Alternative lengths: 20 m, 25 m, 30 m, 40 m, 50 m. Screened cable for frequency converter available on request
Supply voltage : 3 x 400-415 Volt 50 Hz DOL
Maximum installation depth: 20 m
Ex-protection standard : IEC 60079-1:2014 Class Ex db eb h mb IIB T3,T4 Gb

A= Sensor Version
In addition to the standard sensor these also include Water In Oil Sensor and PT1000 In Stator.

Auto-Couplings:
SEV.XX.65 use P/N 96090992
SEV.XX.80 use P/N 96090993 DN80 or P/N 96102240 DN100
SEV.XXX.100 use P/N 96090994 DN100 or P/N 96102241 DN150
